상세 사양 TL 12

Data

용량( 2대의  L 6를 연결)

12 톤

16 load bearing rollers 85 x 85 mm (mounted in moving frames), loading height

110 mm

2 rotating platforms 170 mm Ø with axial thrust bearing, rotatable (as a tandem unit)

±40°

3 adjustable positions from

660-1000 mm

Handlebar with pulling eye (a second handlebar is supplied for use as transport trolley L 6)

1080 mm

중량

105 kg
